เครื่องพิมพ์ เลเซอร์ ชนิด UV รุ่น 7810
UV Laser Marking System
The 7810 UV laser marking system delivers high-contrast, permanent codes enabling product lifetime track and trace for pharmaceutical, medical device and cosmetic manufacturers. Videojet 7810 UV Laser Printer prevents the risk of counterfeiting and meet industry regulations with crisp, vision readable 2D codes on white HDPE and LDPE plastic, and other synthetic fiber materials such as DuPontTM Tyvek®.
- คำอธิบาย
- Brand
คำอธิบาย
| Value | |
| Laser Tube | Pulsed Nd: YVO4 laser (Vanadat), diode-pumped |
| Maximum Power | 2-Watt |
| Laser Cooling | Air cooled |
| Maximum Print Speed | 500 characters/sec |
| Maximum Line Speed | 984 ft/min (300 m/min) |
| Environmental Protection | Marking unit IP20 /Supply unit IP21 |
| Beam Output | Steered beam |
| Laser Source Expected Life | 15,000-25,000 hours |
| Laser Wavelength Options | 355 nm |
| Focal Distance Options | SS10 and SS7 with four focusing optics (f =103 mm/160 mm/214 mm/511 mm) |
| Maximum Mark Window | From 64 x 76 mm2 (SS10, f = 103 mm) to 375 x 375 mm2 (SS10/SS7, f = 511 mm) |
| Standard I/O Connectivity | Ethernet |
| Standard User Interface | Smart Graph (on optional external Windows 7 PC) |
| Optional User Inteface | – |
| Plant Air Used | no |
| Certifications/Approvals | CE, CB, TÜV/NRTL |
Brand
Video Jet
